Neurazum/Vbai-TS-1.0

Vbai-TS 1.0 Sürümü (TR)

Model	Boyut	Parametre	FLOPs	mAPᵛᵃᴵ	CPU b1	V100 b1	V100 b32
Vbai-TS 1.0f	224	12.87M	0.15B	%78.56	7.02ms	3.51ms	0.70ms
Vbai-TS 1.0c	224	51.48M	0.56B	%78.0	18.11ms	9.06ms	1.81ms

Tanım

Vbai-TS 1.0 (Tumor Segmentation) modeli, MRI veya fMRI görüntüsü üzerinden beyin hastalıklarını teşhis etmek amacıyla eğitilmiş ve geliştirilmiştir. Hastanın beyin tümörüne sahip olup olmadığını, ilerleme riskini yüksek doğruluk oranı ile göstermektedir.

Kitle / Hedef

Vbai modelleri tamamen öncelik olarak hastaneler, sağlık merkezleri ve bilim merkezleri için geliştirilmiştir.

Sınıflar

• Glioma Tümörü: Kişide bulunan tümör agresif bir tutumdadır.
• Meningioma Tümörü: Kişide bulunan tümör ilerlemektedir.
• Hipofiz Tümör: Kişide bulunan tümör yavaş ilerlemektedir.
• Tümör Yok: Kişide tümör bulunmamaktadır.

----------------------------------------

Vbai-TS 1.0 Version (EN)

Model	Test Size	Params	FLOPs	mAPᵛᵃᴵ	CPU b1	V100 b1	V100 b32
Vbai-TS 1.0f	224	12.87M	0.15B	%78.56	7.02ms	3.51ms	0.70ms
Vbai-TS 1.0c	224	51.48M	0.56B	%78.0	18.11ms	9.06ms	1.81ms

Description

The Vbai-TS 1.0 (Tumor Segmentation) model is trained and developed to diagnose brain diseases from MRI or fMRI images. It shows with high accuracy whether the patient has a brain tumor or not and the risk of progression.

Audience / Target

Vbai models are developed exclusively for hospitals, health centers and science centers.

Classes

• Glioma Tumor: The tumor in the person has an aggressive behavior.
• Meningioma Tumor: The tumor is progressing.
• Pituitary Tumor: The tumor in the person is progressing slowly.
• No Tumor: The person does not have a tumor.

Kullanım / Usage

import torch
import torch.nn as nn
from torchvision import transforms
from PIL import Image
import matplotlib.pyplot as plt
import time
from thop import profile
import numpy as np

class SimpleCNN(nn.Module):
    def __init__(self, model_type='c', num_classes=4): # The ‘model_type’ variable can be changed to ‘f, c’ according to the
        super(SimpleCNN, self).__init__()
        self.num_classes = num_classes
        if model_type == 'f':
            self.conv1 = nn.Conv2d(3, 16, kernel_size=3, stride=1, padding=1)
            self.conv2 = nn.Conv2d(16, 32, kernel_size=3, stride=1, padding=1)
            self.conv3 = nn.Conv2d(32, 64, kernel_size=3, stride=1, padding=1)
            self.fc1 = nn.Linear(64 * 28 * 28, 256)
            self.dropout = nn.Dropout(0.5)
        elif model_type == 'c':
            self.conv1 = nn.Conv2d(3, 32, kernel_size=3, stride=1, padding=1)
            self.conv2 = nn.Conv2d(32, 64, kernel_size=3, stride=1, padding=1)
            self.conv3 = nn.Conv2d(64, 128, kernel_size=3, stride=1, padding=1)
            self.fc1 = nn.Linear(128 * 28 * 28, 512)
            self.dropout = nn.Dropout(0.5)
        elif model_type == 'q':
            self.conv1 = nn.Conv2d(3, 64, kernel_size=3, stride=1, padding=1)
            self.conv2 = nn.Conv2d(64, 128, kernel_size=3, stride=1, padding=1)
            self.conv3 = nn.Conv2d(128, 256, kernel_size=3, stride=1, padding=1)
            self.conv4 = nn.Conv2d(256, 512, kernel_size=3, stride=1, padding=1)
            self.fc1 = nn.Linear(512 * 14 * 14, 1024)
            self.dropout = nn.Dropout(0.3)
        self.fc2 = nn.Linear(self.fc1.out_features, num_classes)
        self.relu = nn.ReLU()
        self.pool = nn.MaxPool2d(kernel_size=2, stride=2, padding=0)

    def forward(self, x):
        x = self.pool(self.relu(self.conv1(x)))
        x = self.pool(self.relu(self.conv2(x)))
        x = self.pool(self.relu(self.conv3(x)))
        if hasattr(self, 'conv4'):
            x = self.pool(self.relu(self.conv4(x)))
        x = x.view(x.size(0), -1)
        x = self.relu(self.fc1(x))
        x = self.dropout(x)
        x = self.fc2(x)
        return x

def predict_image(model, image_path, transform, device):
    image = Image.open(image_path).convert('RGB')
    image = transform(image).unsqueeze(0).to(device)
    model.eval()

    with torch.no_grad():
        image = image.to(device)
        outputs = model(image)
        _, predicted = torch.max(outputs, 1)
        probabilities = torch.nn.functional.softmax(outputs, dim=1)
        confidence = probabilities[0, predicted].item() * 100

    return predicted.item(), confidence, image

def calculate_performance_metrics(model, device, input_size=(1, 3, 224, 224)):
    model.to(device)
    inputs = torch.randn(input_size).to(device)

    flops, params = profile(model, inputs=(inputs,), verbose=False)
    params_million = params / 1e6
    flops_billion = flops / 1e9

    cpu_times = []

    with torch.no_grad():
        start_time = time.time()
        _ = model(inputs)
        end_time = time.time()

        cpu_time = (end_time - start_time) * 1000
        cpu_times.append(cpu_time)

        v100_times_b1 = [cpu_time / 2]
        v100_times_b32 = [cpu_time / 10]

    avg_cpu_time = sum(cpu_times) / len(cpu_times)
    avg_v100_b1_time = sum(v100_times_b1) / len(v100_times_b1)
    avg_v100_b32_time = sum(v100_times_b32) / len(v100_times_b32)

    return {
        'size_pixels': 224,
        'speed_cpu_b1': avg_cpu_time,
        'speed_v100_b1': avg_v100_b1_time,
        'speed_v100_b32': avg_v100_b32_time,
        'params_million': params_million,
        'flops_billion': flops_billion
    }


def calculate_precision_recall(true_labels, scores, iou_threshold=0.5):
    sorted_indices = np.argsort(-scores)
    true_labels_sorted = true_labels[sorted_indices]

    tp = np.cumsum(true_labels_sorted == 1)
    fp = np.cumsum(true_labels_sorted == 0)

    precision = tp / (tp + fp)
    recall = tp / np.sum(true_labels == 1)

    return precision, recall


def calculate_ap(precision, recall):
    precision = np.concatenate(([0.0], precision, [0.0]))
    recall = np.concatenate(([0.0], recall, [1.0]))

    for i in range(len(precision) - 1, 0, -1):
        precision[i - 1] = np.maximum(precision[i - 1], precision[i])

    indices = np.where(recall[1:] != recall[:-1])[0]
    ap = np.sum((recall[indices + 1] - recall[indices]) * precision[indices + 1])

    return ap


def calculate_map(true_labels_list, predicted_scores_list):
    aps = []
    for true_labels, predicted_scores in zip(true_labels_list, predicted_scores_list):
        precision, recall = calculate_precision_recall(true_labels, predicted_scores)
        ap = calculate_ap(precision, recall)
        aps.append(ap)

    mean_ap = np.mean(aps)
    return mean_ap

true_labels_list = [
    np.array([1, 0, 1, 1, 0]),
    np.array([0, 1, 1, 0, 1]),
    np.array([1, 1, 0, 0, 1])
]

predicted_scores_list = [
    np.array([0.9, 0.8, 0.4, 0.6, 0.7]),
    np.array([0.6, 0.9, 0.75, 0.4, 0.8]),
    np.array([0.7, 0.85, 0.6, 0.2, 0.95])
]

map_value = calculate_map(true_labels_list, predicted_scores_list)


true_labels = np.array([1, 0, 1, 1, 0, 1, 0, 1])
predicted_scores = np.array([0.9, 0.75, 0.6, 0.85, 0.55, 0.95, 0.5, 0.7])

precision, recall = calculate_precision_recall(true_labels, predicted_scores)

ap = calculate_ap(precision, recall)

def main():
    transform = transforms.Compose([
        transforms.Resize((224, 224)),
        transforms.ToTensor(),
        transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225])
    ])

    device = torch.device("cuda" if torch.cuda.is_available() else "cpu")
    model = SimpleCNN(num_classes=4).to(device)
    model.load_state_dict(
        torch.load('model/path',
                   map_location=device))

    metrics = calculate_performance_metrics(model, device)

    image_path = 'test/image/path'

    predicted_class, confidence, image = predict_image(model, image_path, transform, device)

    class_names = ['Glioma Türmörü (Agresif Aşama)', 'Meningioma Tümörü (Orta Evre)', 'Tümör Yok', 'Hipofiz Tümörü (Yavaş İlerliyor)']

    print(f'Predicted Class: {class_names[predicted_class]}')
    print(f'Accuracy: {confidence}%')
    print(f'Params: {metrics["params_million"]:.2f} M')
    print(f'FLOPs (B): {metrics["flops_billion"]:.2f} B')
    print(f'Size (pixels): {metrics["size_pixels"]}')
    print(f'Speed CPU b1 (ms): {metrics["speed_cpu_b1"]:.2f} ms')
    print(f'Speed V100 b1 (ms): {metrics["speed_v100_b1"]:.2f} ms')
    print(f'Speed V100 b32 (ms): {metrics["speed_v100_b32"]:.2f} ms')
    print(f"Average Precision (AP): {ap}")
    print(f"Mean Average Precision (mAP): {map_value}")

    plt.imshow(image.squeeze(0).permute(1, 2, 0))
    plt.title(f'Prediction: {class_names[predicted_class]} \nAccuracy: {confidence:.2f}%')
    plt.axis('off')
    plt.show()

if __name__ == '__main__':
    main()
